55/64 in. Carbide TiAIN Finish 140 Deg. Through Coolant Replaceable Tip Drill

  • Item Code: 0012604
  • Brand: Dormer
  • Unit Size: 1

Description

R950 Hydra range carbide drill heads are interchangeable, so you only need to replace the head, for a very cost efficient, high performance drill. The heads come with coolant feed channels, which fit precisely onto the grooves in the bodies. Manufactured from premium carbide for high performance drilling and longer tool life, R950 drill heads have a special Ti-phon coating which improves performance when drilling harder materials and ensures a longer lasting tool. With a geometry designed for optimum performance when drilling steels, R950 Hydra drill heads have a 140 degree split point to reduce the push force needed and to help with self-centering. Please see H853, H855 and H858 Hydra bodies for use with these drill heads.

Features Tech Specs

Features

Back To Top
    • High productivity across a wide range of materials
    • The R950 head is recommended for steels
    • Consistently high performance, even after numerous head changes

Tech Specs

Back To Top
Metric Diameter 21.83 mm
Fractional Diameter 55/64"
Material Solid Carbide
Point Angle 140 Deg.
Coating/Finish Ti-phon
Brand Dormer
Decimal Diameter 0.8594"
Product Type Replaceable Drill Tip
Cutting Direction Right
