8 mm HSS TiN Coated RH 3 Flute 60 Deg. Straight Shank Single End Countersink
- Item Code: 5972782
- Brand: Dormer
- Unit Size: 1
Description
Countersink with 3-flutes, 60? chamfering angle, maximum diameter 8.00mm with an overall length of 50mm and a head length of 8.5mm and 6mm straight shank, according to DIN 334 C standard for deburring and chamfering holes with a minium hole diameter of 2.00mm, HSS with standard TiN coating for machining steel and cast steel, grey, malleable, ductile and compacted graphite cast-iron, wrought and cast aluminium and copper or copper alloys
Tech Specs
Back To Top| Shank Style | Cylindrical shank |
|---|---|
| Brand | Dormer |
| Overall Length Metric | 50 mm |
| Point Angle | 60 Deg. |
| Coating/Finish | TiN |
| Overall Length Inches | 1.9685" |
| Metric Diameter | 8.00 mm |
| Material | High Speed Steel |
| Cutting Direction | Right |
| Number of Flutes | 3 |
