0.1880 Inch Dia. x 4.000 Inch Overall Length x 0.218 Inch Min Dia. S-Clamp RH Boring Bar

  • Item Code: CCBI18745R-WG
  • Brand: WIDIA
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Min Bore Diameter 0.2180 Inch
Insert Shape Diamond
Brand WIDIA
Cutting Height 0.0100 Inch
Head Length 0.4230 Inch
Overall Length 4 Inch
Unit of Measure Inch
Axial Rake Angle 5 Degree
Hand of Tool Right
Lead Angle -5 Degree
Shank Diameter 3/16 Inch
Drive Size T6
Included Angle 80
Product Type Boring Bar
Grade WG
Insert Style CCBI
Shank Length 3.5770 Inch
Tool Length 4 Inch
