M2.6 Thread, Torx Plus Clamping Screw for Indexable Boring Bars and Milling
- Item Code: N0056111
- Brand: Komet
- Unit Size: 1
Description
Compatible with Cartridges and Inserts, Kometric and MicroKom Series
Tech Specs
Back To Top| Cartridge Size Compatibility | FZ16; FZ20; UKS8 |
|---|---|
| Complete Insert Compatibility | TOHX 090204FN-G12; TOHX090204EL-G06 |
| Head Type | Countersunk |
| Screw Length | 0.2441 Inch |
| Toolholder Style Compatibility | F10 20 |
| Drive Type | Torx Plus |
| Series | Kometric; MicroKom |
| Indexable Tool Type | Boring Bar; Milling |
| Thread Size | M2.6 |
| Hardware Compatibility | Cartridge; Insert |
| Torx Size | TP8 |
| Screw Type | Clamping Screw |
| Brand | Komet |
| Product Type | Clamping Screw |
